MATRIX X-SPDIF 2 32Bit/768kHz DSD512 Hifi Audio USB Interface

MATRIX X-SPDIF 2 32Bit/768kHz DSD512 Hifi Audio USB Interface

  • Type: Portable
  • Inputs: USB Type-B
  • Outputs: RCA
  • PCM Sampling Frequencies: 176.4 kHz
  • PCM Sampling Frequencies: 192 kHz
  • PCM Sampling Frequencies: 88.2 kHz
  • PCM Sampling Frequencies: 48 kHz
  • PCM Sampling Frequencies: 44.1 kHz
  • PCM Sampling Frequencies: 705.6 kHz
  • PCM Sampling Frequencies: 352.8 kHz
  • PCM Sampling Frequencies: 96 kHz
  • PCM Sampling Frequencies: 768 kHz
  • PCM Sampling Frequencies: 384 kHz
  • PCM Word Length: 24-bit
  • PCM Word Length: 16-bit
  • PCM Word Length: 32-bit
  • DSD Sampling Frequencies: 2.8224 MHz (DSD64)
  • DSD Sampling Frequencies: 22.5792 MHz (DSD512)
  • DSD Sampling Frequencies: 5.6448 MHz (DSD128)
  • DSD Sampling Frequencies: 11.2896 MHz (DSD256)
  • Model Number: X-SPDIF 2
  • Brand Name: MATRIX
  • Material: Aluminum alloy
















---SpecificationsSplit---

MATRIX X-SPDIF 2 32Bit/768kHz DSD512 Hifi Audio USB Interface12345678



Supported Sample Rate

Optical/Coaxial/AES:PCM 16-24Bit /44.1kHz、48kHz、88.2kHz、96kHz、176.4kHz、192kHzDSD64(DoP)

PCM 16-32Bit /44.1kHz、48kHz、88.2kHz、96kHz、176.4kHz、192kHz、352.8kHz、384kHz、705.6kHz、768kHzDSD64/128/256/(DoP) DSD64/128/256/512(Native)



System Support

Windows7/8/8.1/10 system needs to install the supplied driver.

Mac OS X10.6.4 or above without installing the driver.

Most Android devices can be used via OTG cable.

The iOS devices can be used via Lightning to USB Camera Kit.



Power

Power Supply Specs:

USB bus power supply: 5V/500mA

External power supply: DC 6~9V，≥800mA

Power supply port: outer diameter 5.5mm; inner diameter 2.1mm (+ for inner, - for outer)

NOTE:Do not connect to the power supply with a voltage above 9V, or will cause damage.It will auto disconnect USB bus supply after connected to the external power supply.It needs to connect to the external power supply when using mobile phone or pad which USB port with low current output.



Dimension:133mm×142mm×38mm(L×W×H, including protruding parts)

Weight:1.1KG



$131.70

Original: $439.00

-70%
MATRIX X-SPDIF 2 32Bit/768kHz DSD512 Hifi Audio USB Interface—

$439.00

$131.70
Product image 1
Product image 2
Product image 3
Product image 4
Product image 5

Description

  • Type: Portable
  • Inputs: USB Type-B
  • Outputs: RCA
  • PCM Sampling Frequencies: 176.4 kHz
  • PCM Sampling Frequencies: 192 kHz
  • PCM Sampling Frequencies: 88.2 kHz
  • PCM Sampling Frequencies: 48 kHz
  • PCM Sampling Frequencies: 44.1 kHz
  • PCM Sampling Frequencies: 705.6 kHz
  • PCM Sampling Frequencies: 352.8 kHz
  • PCM Sampling Frequencies: 96 kHz
  • PCM Sampling Frequencies: 768 kHz
  • PCM Sampling Frequencies: 384 kHz
  • PCM Word Length: 24-bit
  • PCM Word Length: 16-bit
  • PCM Word Length: 32-bit
  • DSD Sampling Frequencies: 2.8224 MHz (DSD64)
  • DSD Sampling Frequencies: 22.5792 MHz (DSD512)
  • DSD Sampling Frequencies: 5.6448 MHz (DSD128)
  • DSD Sampling Frequencies: 11.2896 MHz (DSD256)
  • Model Number: X-SPDIF 2
  • Brand Name: MATRIX
  • Material: Aluminum alloy
















---SpecificationsSplit---

MATRIX X-SPDIF 2 32Bit/768kHz DSD512 Hifi Audio USB Interface12345678



Supported Sample Rate

Optical/Coaxial/AES:PCM 16-24Bit /44.1kHz、48kHz、88.2kHz、96kHz、176.4kHz、192kHzDSD64(DoP)

PCM 16-32Bit /44.1kHz、48kHz、88.2kHz、96kHz、176.4kHz、192kHz、352.8kHz、384kHz、705.6kHz、768kHzDSD64/128/256/(DoP) DSD64/128/256/512(Native)



System Support

Windows7/8/8.1/10 system needs to install the supplied driver.

Mac OS X10.6.4 or above without installing the driver.

Most Android devices can be used via OTG cable.

The iOS devices can be used via Lightning to USB Camera Kit.



Power

Power Supply Specs:

USB bus power supply: 5V/500mA

External power supply: DC 6~9V，≥800mA

Power supply port: outer diameter 5.5mm; inner diameter 2.1mm (+ for inner, - for outer)

NOTE:Do not connect to the power supply with a voltage above 9V, or will cause damage.It will auto disconnect USB bus supply after connected to the external power supply.It needs to connect to the external power supply when using mobile phone or pad which USB port with low current output.



Dimension:133mm×142mm×38mm(L×W×H, including protruding parts)

Weight:1.1KG
